Review Yamaha MG06 6-input stereo mixer, 2 mic inputs, 2 stereo inputs
$137.99
($137.99 Incl. tax)
in stock
6-input stereo mixer • 2 mic inputs, 2 stereo inputs.
B's Music Shop.
-
Premium ShippingFast and secure
-
Quality InspectionEach item is quality inspected by a trained B's Music Shop technician
-
Stay In TouchReceive order updates from our knowledgable staff
-
Financing OptionsIn store and online with Affirm
Description
Featuring an intuitive, easy-to-use interface, MG Series boasts an extensive lineup of compact mixing consoles with models ranging from six to twenty channels that are ideal for a diverse range of users and applications. Embodying the pursuit of design excellence, MG Series incorporates many of the same technologies developed for use in high-end professional consoles, including studio-quality preamps, powerful digital processing and a rugged construction. Shape your sound with confidence and deliver peak performance with mixing consoles that are unrivalled in their class.
|
|
|
---|---|---|
I/O | Phantom power | +48 V |
Input Channels | Mono[MIC/LINE] | 2 |
Mono/Stereo[MIC/LINE] | - | |
Stereo[LINE] | 2 | |
Output Channels | STEREO OUT | 2 |
MONITOR OUT | - | |
PHONES | 1 | |
AUX SEND | - | |
GROUP OUT | - | |
Bus | Stereo: 1 | |
Input Channel Function | PAD | 26 dB (Mono) |
HPF | 80 Hz, 12 dB/oct (Mono) | |
COMP | - | |
EQ HIGH | (Mono) Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving | |
EQ MID | - | |
EQ LOW | (Mono) Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving | |
PEAK LED | LED turns on when post EQ signal reaches 3 dB below clipping | |
Level Meter | 2 x 7 -segment LED meter [PEAK, +6, +3, 0, -3, -10, -20 dB] | |
Total harmonic distortion | 0.01 % @ +8dBu (20 Hz to 20kHz), GAIN knob: Min, 0.003 % @ +18dBu (1kHz), GAIN knob: Min | |
Frequency response | +0.5 dB/-0.5 dB (20 Hz to 20 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min | |
Hum & noise level | Equivalent input noise | -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max) |
Residual output noise | -102 dBu (STEREO OUT, STEREO LEVEL knob: Min) | |
Crosstalk | -88 dB | |
Power requirements | PA-130 (DC12 V/1.0 A, Cable length = 1.8 m), 120 V, 60 Hz, MU18 (DC12 V/1.5 A, Cable length = 1.5 m), 100 V-240 V, 50 Hz/60 Hz or equivalent recommended by Yamaha | |
Power consumption | 12 W | |
Dimensions | W | 149 mm (5.9") |
H | 62 mm (2.4") | |
D | 202 mm (7.9") | |
Net weight | 0.9 kg (1.98 lbs.) | |
Accessories | Included Accessory: AC Adaptor, Owner’s Manual, Technical Specifications, Optional Accessory: Mic Stand Adaptor BMS-10A | |
Others | Operating Temperature: 0 to +40˚C |
